Flat pack G+1 Accommodation containers

د.إ 395,300,00

Building Area : 292 m²

Size of Ground Floor : 24.4*6.1*2.56 m

Size of Second Floor : 24.4*6.1*2.56 m

Description

Name Description Specification
Main Structure (preassembled in our factory) Corner Post Galvanized cold rolled steel, thickness=2.0mm, zinc=80g/m2

——————————————————————–

Corner fittings Galvanized steel material, thickness=4.0mm, zinc=80g/m2

——————————————————————–

Roof Main Beam Galvanized cold rolled steel, thickness=2.0mm, zinc=80g/m3

——————————————————————–

Floor Main Beam Galvanized cold rolled steel, thickness=2.0mm, zinc=80g/m4

——————————————————————–

Roof Secondary Beam Galvanized cold-formed thin- walled C section steel,
thickness=1.5mm, zinc=80g/㎡——————————————————————–
Floor Secondary Beam Galanized cold-formed thin- walled C section steel,
thickness=2.0mm, zinc=80g/㎡——————————————————————–
Coating
(similar with enamel)
Graphene powder electrostatic spraying,
thickness=80-100μmSimilar with enamel, 30 years lifetime at least——————————————————————–
Roof (preassembled in our factory) Roof Covering Galvanized steel plate, 360° seal, white grey color, thickness=0.4mm

——————————————————————–

Insulation Glass fiber roll with single side aluminum foil, density:
14kg/m3, thickness=50mm
A grade noncombustible——————————————————————–
Ceiling Galvalume steel plate, white grey color thickness=0.4mm

——————————————————————–

Floor (preassembled in our factory) PVC floor PVC waterproof floor thickness=1.0mm

——————————————————————–

Cement Fibre board Thickness=18mm
Density: ≥1.3g/cm³——————————————————————–
Moisture proofing course PE Moisture proof film

——————————————————————–

Wall Glass fiber sandwich panel Outside: 0.4mm galvalume steel sheet, ivory white

——————————————————————–

Insulation: 50mm glass fiber, Density: 55kg/m3, A grade noncombustible

——————————————————————–

Inside: 0.4mm galvalume steel sheet, white grey

——————————————————————–

Door Entrance door*1
Bathroom door*1
840*2035mm (width*height) Special made fireproof steel door

——————————————————————–

Windows Double glazing PVC window
Glass thickness=4mm
Within screen window and security bar
900*1100mm for bedroom
500*800mm for bathroom——————————————————————–
Exhaust Fan For shower location White color
Accessories Decoration lines Skirting lines, Ceiling decoration lines, corner decoration accessories

——————————————————————–

Others Connections, nails, etc

——————————————————————–

For containers connection
Ensure whole building’s stability
Galvanized

——————————————————————–

Electric system Wires with PVC in the wall
(preassembled in our factory)
As customers’ requested
Standard——————————————————————–
Sockets
Switches
LED Light
Industrial plug
(preassembled in our factory)
Plumbing system
(preassembled in
Water supply pipe PPR pipe

——————————————————————–

our factory) Drainpipe UPVC pipe

——————————————————————–

Bathroom
Fittings
Shower Independent shower room

——————————————————————–

Toilet White

——————————————————————–

Wash basin Luxury cabinet

——————————————————————–
